LIFEGUARD® TPLX – Industrial Chain Lighting

Manufactured for use in Mining, Building and Construction, Shows and Events, Military, Shipbuilding and Salvage.





Our TPLX chain lights are built tough for construction sites and deliver the brightest lighting on the market. With a lamp IP68 rating, they’re perfect for both indoor and outdoor use, no matter the conditions.
Made as a standard 25m length (10 lamps), but we can customize them to suit your needs! Plus, they’re fully serviceable, making them a smart long-term investment.





Why Choose TPLX?

– Keep your site safe and productive during Daylight Savings and evenings
– Impact-resistant lamp fittings
– Daisy chain up to 225m
– Long-life robust LEDs

Description

LIFEGUARD® TPLX – INDUSTRIAL CHAIN LIGHTING

  • 6500K colour temperature
  • 27,000 lumens total, 240W
  • 10A, 15A, or 16A IEC plugs & connectors
  • 3c 2.5mm Flat Flex
  • 25m standard length, 10 lamps per chain (custom available)
  • 220-240V AC
  • IP68 rated Lamps

Manufactured for use in Mining, Building and Construction, Shows and Events, Military, Shipbuilding and Salvage.



SPECIFICATIONS
Lamp24W LED each
IP Rating68 (@ 1.5m)
Connection10A or 15A flat pin,16A IEC
Voltage220V-240V AC (double insulated)
Cable2.5mm2 – 3c Flat Flex
LensPolycarbonate
Length12.5m or 25m



Part Number              Length        Plug      Lamps       Watts   Voltage               Wire
LG15TPLX2510A25m10A10x LED240220-240V AC2.5mm²
LG15TPLX12.510A12.5m10A5x LED120220-240V AC2.5mm²
LG15TPLX2516A25m16A10x LED240220-240V AC2.5mm²
LG15TPLX12.516A12.5m16A5x LED120220-240V AC2.5mm²
